breathable skin-friendly fabric making 1600 SSS spunbond non wovenn fabric machine
What is SSS spunbond fabric making machine?
S is spunbond nonwovens (spunbond nonwovens), single S is single layer spunbond nonwovens, double S is double layer composite spunbond nonwovens, triple S is triple layer composite spunbond nonwovens.
They are durable and disposable. Insulation, conduction. Soft, stiff sex. Fineness, eliminability. Anisotropy, anisotropy. Filters, breathable and impermeable. Elastic or stiff. Light, loose and warm. Thin as a cicada wing, thick as a blanket. Waterproof and wet. Ironing, stitching and molding. Flame retardant, anti-static. Water permeable, waterproof, wear-resistant, fluffy. Aging resistance, good elasticity, high moisture absorption, good water resistance
Spunbond fabrci making will help your profit , for example 3.2 M
| Type HHM S 3.2 Fabric Making line , Output Daily :10 Ton |
| Items | Cost USD/ton | Cost /year | Memo |
| Polypropylene PP Chips | $1,400 | $5,110,000 | |
| Electrictity Power | $90 | $328,500 | |
| Laborer | $32 | $116,800 | |
| Machine Parts consumption | $3 | $10,950 | |
| Total | | $5,566,250 | |
| Non woven Fabric price | $1,881 | $6,865,650 | |
| Return per year | | $1,299,400 | |
HHM 1600 m SSS Double beam fabric making line date
| Width | 1600 M |
| Gsm | 9 - 100 gsm |
| Output per day | 12 - 17 Ton |
| Machine Speed | ≦ 550 m / min |
| Transformer | ≈ 630 KVA |
| Power Consumption | 650º - 800º / Ton |
| Machine Size | 50 * 15 *12 M |
SSS Model
| Effective width(mm) | 1600 | 2400 | 3200 | 4000 | 4800 |
| Output(ton/year) | 5800T | 7300T | 10000T | 12400T | 14000T |
| GMS Range(g/㎡) | 9-100 | 9-100 | 9-100 | 9-100 | 9-100 |
| Max.speed(m/min) | 550 | 550 | 550 | 550 | 550 |
SMS Model
| Effective width(mm) | 1600 | 2400 | 3200 | 4000 | 4800 |
| Output(ton/year) | 3200T | 5100T | 7000T | 8700T | 10500T |
| GMS Range(g/㎡) | 9-100 | 9-100 | 9-100 | 9-100 | 9-100 |
| Max.speed(m/min) | 350 | 350 | 350 | 350 | 350 |
SMMS
| Effective width(mm) | 1600 | 2400 | 3200 | 4000 | 4800 |
| Output(ton/year) | 4000T | 6200T | 5400T | 10500T | 12700T |
| GMS Range(g/㎡) | 9-100 | 9-100 | 9-100 | 9-100 | 9-100 |
| Max.speed(m/min) | 450 | 450 | 450 | 450 | 450 |
Image of non wovne fabric making line
1) Parts of spunbonded nonwoven fabric production line:
Recycle extruder---->Main extruder---->Filter---->Metering pump---->Monomer suction device--->Spinning box(ENKA/KASEN spinneret)---->
Quenching air chamber---->Stretching device---->Web former---->Calender---->Winder---->Slitter
2) Spunbonded process and technical flow chart:
Additive(Recycling off-cut fabric)---->Raw material----> Melting---->Filtering---->Measuring ---->Spinning---->Cooling---->Stretching---->
Web forming---->Calendering---->Winding----> Cutting---->Final product
system maim parts
Name:Main Extruder
Brand:HHM
Original:China
Diameter:Φ135mm for 1.6m,Φ170mm for 3.2m,
Max speed: 75r/min for 1.6m , 85r/min for 3.2m
Motor:90kw for 1.6m , 132kw for 3.2m
Name: Spinning Box
Orifice number:11019 for 1.6m , 17651 for 3.2m
Orifice diameter:Φ0.45mm
L/D=4:1
Max temperature:300℃
Fuction : for spining the PP flament.
| Name | Spinning box |
| Orifice number | 1109 for 1.6 m , 17651 for 3.2 m |
| Orifice diameter | ￠0.45mm L/D 4 : 1 |
| Max temperature | 300℃ |
| Fuction | For spinning the PP flow |
Precisely heavily CNC center keep machining parts beyond customer request .
Exhibition
Our service
Pre-Sales Service
Design and make plan for the workplace.
Offer sketch map of machine and place it into the workplace
After-sales Service
Training and training how to use the machine.
Engineers can repair machinery.
